ThermaData Pharm Vaccine Data Loggers

ThermaData Pharm WiFi data loggers are a battery-powered, cost-effective temperature monitoring system that remotely records storage and transport temperatures of perishable items such as vaccines, medications, and perishable food edibles.

The ThermaData Pharm is available in two options, the TD1F-PHM with one internal sensor and one external sensor or the TD2F-PHM which has two external sensors.

Each unit has an intuitive LCD display; temperature, WiFi connection status, recorded max/min temperatures, alarm status and battery life.

Simple to install, the logger once operational will transmit the recorded data to an internet connected WiFi router which can then be accessed and viewed from a PC, laptop or tablet anywhere in the world.

At programmable intervals, the loggers record the temperature of both sensors, logging up to a maximum of 18,000 readings (9,000 from each sensor). Each recorder incorporates a red and green LED. The flashing green LED indicates that the logger is active/recorded and the flashing red LED indicates that the custom alarms have been exceeded. Each logger communicates directly with the WiFi router at set intervals to send data over the internet into ThermaData Studio. The information is available to be analyzed and exported in a report format. Each unit comes complete with USB cable, wall bracket and FREE ThermaData Studio software (unlicensed) available for download on our website.

Each thermistor probe is enclosed in a sealed bottle and includes a fixed two meter PUR/PVC cable. To start monitoring, simply unscrew and top up with glycol solution (50ml bottle supplied). Please note: The TD1F model is supplied with an external remote probe and an internal sensor. The TD2F model is supplied with two external remote sensors. For more information, contact our sales office.

How does the ThermaData Pharm WiFi Logger work?

Using each logger's unique ID, ThermaData Studio creates a secure connection between the logger and the software that can be accessed and viewed anytime and anywhere with an internet connection.

Each logger communicates directly with the WiFi router at set intervals to send data over the internet into ThermaData Studio.

The information is available to be analyzed and exported in a report format.

Logiciel ThermaData Studio

Powerful and sophisticated, yet user-friendly, ThermaData Studio software organizes and analyzes temperature data to provide management information.

ThermaData Studio software has the ability to display up to 32 traces on a graph, trace colors are user selectable. All files can be viewed as thumbnail icons for easy identification.

The software allows the user to program the sampling rate/logging interval (0.1 to 330 minutes), the communication interval (synchronization) with the PC, the real time clock, °C or ° F and a manual start option. It is also possible to include a user ID for each recorder.
